0.82m Pre-wall Freestanding W.C Frame & Wortex Matt Black Rimless Toilet with Seat & Bronze Flush Plate

Integrated bathroom toilet system developed for concealed installation, combining a matt black seat, 0.82 m floor-standing W.C. frame, built-in cistern and flush plate.

The wall-hung porcelain pan provides a durable, non-porous surface for easy cleaning. Its D-shaped rimless design supports a compact profile and improved hygiene, while tornado flush technology enhances rinsing performance. A soft-close sandwich seat is included for quieter operation and added user comfort. The rear outlet allows concealed waste connection for a cleaner finish.

The 820mm W.C. frame is designed for floor-mounted pre-wall applications and provides the required support for suspended pan installation. Its reduced-height format is suitable for layouts where installation depth and height need to be carefully managed. The frame accommodates the concealed cistern and associated pipework within the structure, while supplied brackets assist with secure fixing and alignment. The included W.C. bend enables connection between the pan outlet and the concealed discharge run.

The cistern is integrated within the frame and fitted with a 3 litre / 6 litre dual flush mechanism to support controlled water usage. This arrangement allows reduced-volume or full-volume discharge depending on operational requirement, improving water efficiency without compromising flushing performance. Locating the cistern behind the finished wall also helps protect internal working components and maintain a more ordered installation.

The brushed bronze flush plate is intended for front access only and acts as the visible control interface for the system. Its rectangular form incorporates two pneumatic push buttons for dependable activation of the dual flush function. After completion, only the pan, seat and flush plate remain visible, giving the installation a neat, integrated appearance.

Features & Benefits:

Wall Hung Toilet Pan:

• Matt black finish for a bold modern look
• D-shaped design for a contemporary feel
• Durable porcelain construction
• Tornado flush for efficient rinsing
• Rimless bowl for easier cleaning
• Rear outlet for concealed waste connection
• Height: 365mm
• Width: 365mm
• Projection: 495mm
• 2-year guarantee, extendable to 15 years on registration

Concealed Cistern & W.C. Frame:

• Slim floor mounted pre-wall frame
• Designed for wall hung toilet installation
• Concealed cistern for a neat finish
• WRAS approved
• Includes brackets and W.C. bend
• Dual flush 3L/6L cistern
• Suitable for front or top access
• Height: 820mm
• Width: 400mm
• 2-year guarantee, extendable to 5 years on registration

Flush Plate:

• FInished in brushed bronze
• Dual-button design
• Pneumatic operation for smooth flushing
• Height: 145mm
• Width: 215mm
• 2-year manufacturer guarantee
